DAAB MT
DAAB MT
| Model Variant | Part Number | Application | Operator Type | Max Cycles Per Hour | Power Supply | Leaf Length (Minimum - Maximum) | Gate Obstacle Detection |
|---|---|---|---|---|---|---|---|
| DAAB MT | MT | Industrial | Hydraulic | Continuous | 230V | 0.10 - 3.50 | Encoder |
Key features
- Fits swing gates up to max 3.5 metres per leaf.
- Double worm gear box - optimal for applications in windy locations
- Self-locking keeps the gate leaf in position even if the power is broken.
- Delivered with an optimal arm system for smooth opening and closing.
- Good for the toughest applications.
- Manages temperatures down to -45°
- Plastic cover and silumin alloy base. The cover is also available in stainless steel, at additional cost
- Electrical Motor 3-phase as standard. 1-phase is optional.
Product details
Max. Leaf Size: 3.5m
Max. Leaf Weight: 300kg
Opening Time/Speed: 8 - 16s
Max. Usage: Continuous
Drive Unit: 1- or 3-phase
Voltage: 230/400 VAC
Max Torque: 275 - 550 Nm
Reduction Ratio: 750
